Features
1.Efficiency: Up to 95%.
2.No work noise,normal use can be run for many years without maintenance.
3.Strong ability of resist concussion.
4.Protection: Battery Low Alarm/Battery Shut down/Over Voltage/Over Temp/Output Short/Input polarity reverse/Over load.
5.A variety input and output mode:12V input, 24V input;220V AC output,110V AC output,fully able to meet domestic and foreign users of the exchange of electricity demand.
6.Aluminum products,high-pressure plasma process Ti surface,high hardness, chemical composition and stability,anti-oxidation,fashion appearance.
Product Introduction
Modified sine wave inverter has everything you are looking for excellent quality, whether you connect it to the car cigarette socket, or connect it to the battery, both can be directly converted to alternating current. It can be used on various types of household appliances, allowing you to work in the business, driving tours, power outages when the emergency, giving you a steady stream of power.
Specification
| Tsolar/MI-60-1 | Tsolar/MI-60-1 | Tsolar/MI-60-3 | |||||
| Rated Power | 100W | 300W | 500W | ||||
| Output | |||||||
| AC Voltage Regulation | 220VAC±5% | ||||||
| WaveForm | Modified Sine Wave | ||||||
| Display | |||||||
| LED/LCD Display | Digital LED Display | ||||||
| Battery(External Connection) | |||||||
| Battery Voltage | 12V | 24V | 12V | 24V | 12V | 24V | |
| Floating Charge Voltage | 13.5V | 27V | 13.5V | 27V | 13.5V | 27V | |
| Overcharge Protection | 15.5V | 31V | 15.5V | 31V | 15.5V | 31V | |
| Parameters&Protections | |||||||
| Maximum Work Temperature | ≦60℃ | ||||||
| Protections | Over Temperation, Low Battery, Over Voltage, Over Load. Short Circuit... | ||||||
| Cooling | Fan | ||||||
| Physical | |||||||
| Shell Material | Aluminum Alloy | ||||||
| Dimension, D x W x H(mm) | 105x65x40mm | 150x96x58 | 190x96x58 | ||||
| Weight(Kg) | 0.35Kg | 0.6Kg | 0.88Kg | ||||
| Operating Environment | |||||||
| Humidity | 5% to 95% Relative Humidity(Non-Condensing) | ||||||
| Operating Temperature | 0℃-55℃ | ||||||
| Storage Temperature | (-)10℃-60℃ | ||||||
Product Pictures
